Spirits
Closures
Elevate Your Brand
Stock offerings
| Description | Assembly Print | OD | OAL | T | E | Thread Finish |
|---|---|---|---|---|---|---|
| 33mm Spirits Cap | AN-502-0477 | 1.488 [37.80] | 1.124 [28.55] | 1.273 [32.33] | 1.182 [30.02] | Glass - GPI-360 Plastic / 8 TPI |
| 28mm Spirits Cap | AN-502-0053 | 1.299 [33.00] | 0.863 [21.92] | 1.100 [27.94] | 1.010 [25.65] | Glass - GPI-350 / 8 TPI |
| T-top Cap | 502-0658 | 1.345 [37.17] | 0.723 [18.36] | – | – | Shank diameter 0.886 [22.50] OD and length 0.709 [18.00] |
| 32mm Spirits Cap | 502-0805 | 1.253 [31.83] | 0.736 [18.69] | 1.066 [27.08] | 0.985 [25.02] | 2.5 mm thread pitch |
Dimensions in inches, [mm] in brackets. Custom tooling available on request.
Decorations that differentiate
You don't do ordinary and neither do we. Our robust line of decorative finishing technologies can be combined to help you elevate your brand and stand out from the competition.
- Embossing
- Debossing
- Gradients
- Laser Engraving
- Hot Foil Stamping
- Offset Flexographic Printing
- Digital Embossing
- Screen Printing
- Iridescence
Stand out on the shelf
Set your brand apart with premium finishes on stock closures, or work with our engineers on a custom design.
Start a Consultation
